EC-3000 Wheel Wet Film Thickness Gauge for Paint Coating Measurement
Description
The EC-3000 wet film thickness gauge is a precision wheel-type tool for measuring wet paint coatings. This portable wet film thickness gauge offers 8 calibrated points from 9 to 105μm with dual unit support. The compact wet film thickness gauge suits paint manufacturing and industrial coating quality control.
Specifications
| Measurement Principle | Wheel-type wet film thickness measurement |
|---|---|
| Measurement Range | 0–122μm (0–3.5 oz/ft²) |
| Calibrated Points – Metric | 9, 12, 17, 26, 35, 53, 70, 105μm |
| Calibrated Points – Imperial | 1/4, 1/3, 1/2, 3/4, 1, 3/2, 2, 3 oz/ft² |
| Measurement Units | oz/ft², μm |
| Operating Temperature | -10 to 50°C |
| Operating Humidity | 20–90% RH (non-condensing) |
| Storage Temperature | -20 to 60°C |
| Storage Humidity | 20–90% RH (non-condensing) |
| Power Supply | 2 × AA 1.5V alkaline or 1.2V rechargeable batteries |
| Protection Class | IP20 |
| Housing Material | ABS |
| Dimensions | 109 × 67 × 31mm |
| Weight | Approx. 82g (without batteries) |
